Equinox 800

All-Terrain Multi-Purpose Detector

Detect Modes

Equally adaptable for all target types and ground conditions… just select your detecting location and go!

Great performance in high-trash recreational environments.

Using Multi in this mode is the most versatile for general coin and treasure detecting.

Ideal for detecting fine jewellery and artefacts.

Using Multi in this mode helps the specialist find the widest range of target sizes.

Excels in dry sand, wet sand, and underwater.

Beach mode operates in Multi only, and is designed for typical use in beach conditions.

Good for gold nugget prospecting.

This mode operates high single frequencies of 20 or 40 kHz, optimum for gold targets.

User Interface

The crisp LCD display features large Target ID numbers so you can see your target ID at a glance. All of the information you need when detecting is right there in front of you.

Detect Modes and operating frequency can be instantly changed at the push of a button for a dynamic and uninterrupted detecting experience.

Using the EQUINOX 800 user interface, you can:

View the status of your battery and wireless audio device connections.
Create you own notch discrimination patterns to ignore unwanted targets.
Change the operating frequency, Detect Mode, and Sensitivity on the fly.
Activate All-Metal mode to temporarily disable the current discrimination pattern.
Activate Pinpoint mode to zero-in on a promising target so that you know exactly where to dig.
Adjust an array of essential and advanced detecting functions including Noise Cancel, Ground Balance, Volume Adjust, Threshold Level, Target Tone, Accept / Reject and Recovery Speed.
Customise Advanced Settings to change the way detections are heard, by selecting the number, pitch, and volume of your detection signals.

Plus more!

For detailed information on user interface functionality and operation, download the EQUINOX 600 | 800 Getting Started Guide from the downloads tab.

Multi-IQ

Low frequencies give more depth on large targets, and high frequencies are usually more sensitive to small targets.

With EQUINOX you can operate across the full spectrum of frequencies simultaneously for maximum results.

Read more detailed information and reviews on our game-changing Multi-IQ technology on the Minelab Treasure Talk Blog.

Other Technologies

EQUINOX 800 offers 5 single frequencies of 5, 10, 15, 20 and 40 kHz, giving an expanded 8-times range of 5 to 40 kHz.
Maximum wireless audio compatibility - Connect conventional Bluetooth headphones, high-speed aptX™ Low Latency devices, or the ultra-fast Wi-Stream enabled WM 08 audio module.

Key Features

Simultaneous Multi-Frequency

True intelligent Simultaneous Multi-Frequency for maximum performance, plus a wide range of single frequencies.

Waterproof Design

EQUINOX is fully submersible, ideal for detecting at the beach and in rivers, streams and lakes. (3m / 10-feet)

Sleek & Lightweight

Rugged and lightweight construction allows you to enjoy long detecting sessions in any environment.

High-Speed Wireless Audio

Experience ultra-fast wireless audio with the WM 08, or use fast aptX™ Low Latency / Bluetooth headphones.

8 Custom Search Profiles

Each Detect Mode features 2 custom Search Profiles so you can save your favourite settings in each mode.

Fast & Accurate Target ID

Fast recovery speed with accurate Target ID ensures you won’t miss any valuable targets amongst the trash.

Advanced Settings

Gain even more control of your detector audio with Advanced Settings; you decide how much target information you hear.

Gold Detecting Mode

Gold Mode operates the high single frequencies of either 20 kHz or 40 kHz to detect gold nuggets in mineralised soils.

Specifications

General

Detect Modes	Park \| Beach \| Field \| Gold
Custom Search Profiles	8 (2 per Detect Mode)
User Profile Button	Yes
Operating Frequencies (kHz)	Multi, 5, 10, 15, 20, 40
Noise Cancel	Auto \| Manual (-9 to 9)
Ground Balance	Auto \| Manual
Sensitivity	1–25
Target Volume	0–25
Threshold Level	0–25
Target Identification	50 segment notch discrimination \| Ferrous: -9 – 0 \| Non-ferrous: 1 – 40
Target Tones	1, 2, 5, 50
Tone Break	Ferrous \| Non-ferrous
Tone Pitch	Ferrous \| Non-ferrous
Tone Volume	Ferrous \| Non-ferrous
Depth Indicator	5 levels
Length	1440 mm (56.7")
Weight	1.34 kg (2.96 lbs)
Standard Coil	11-inch Double-D Smart coil with skidplate (waterproof to 3m/10')
Audio Output	In-built loudspeaker • 3.5mm (1/8") headphones (included) • Bluetooth compatible • WM 08 Wi-Stream compatible
Headphones (included)	Wired 3.5mm (1/8") headphones (non waterproof)
WM 08 (included)	Yes
Display	Monochrome LCD with backlight
LCD Backlight	Low \| Medium \| High \| Off
Battery	In-built rechargeable Lithium-ion battery
Battery Life	Approx. 12 hours
Waterproof	Waterproof to 3m/10-feet
Key Technologies	Multi-IQ \| 3F×3 \| Wi-Stream \| Bluetooth \| aptX™ Low Latency
Other Accessories	USB Charging cable (1.5A), Multi Language Screen protectors
Software Upgradeable	Yes, via USB connection (Windows and OSX)
Warranty	3 years control box and coil

In The Box

Equinox 800
Wireless Bluetooth / apt-X Low Latency headphones
WM 08 wireless audio module
USB charging cable with magnetic connector
Multi-language screen protectors
Getting Started Guide English & Russian
