HELIX 5 G2 DI GPS NAV+





HELIX 5 G2 CHIRP DI GPS NAV+
CHIRP Down Imaging Sonar GPS

OVERVIEW
HELIX 5 CHIRP DI GPS G2 | HELIX 5 Series | 410220-1
The HELIX 5 CHIRP DI GPS G2 with the new user interface and operating system, features a brilliant 800H x 480V, 5" 256 colour display with backlight. CHIRP Down Imaging and DualBeam PLUS sonar with 4000 watts PTP power output, Precision Internal GPS Chartplotting with built-in UniMap cartography with a micro SD card slot for optional maps or for saving waypoints. Maximize your angling experience with the Humminbird HELIX 5 CHIRP DI GPS fishfinder GPS system.
CHIRP Frequencies (Out of Box Transducer)
455 kHz: 420-520 kHz
800 kHz: 790-850 kHz
Maximum Depth: 600 feet
CHIRP Frequencies (Optional Purchase Transducer)
Low: 28-75 kHz
Med: 75-155 kHz
High: 130-250 kHz
83/200: 75-155/130-250
50/200: 28-75/130-250
Maximum Depth: 2500 feet
FEATURES
BROADBAND CHIRP SONAR
View low, mid and high Chirp ranges, either individually or all at once.
SWITCHFIRE
Take command of how your sonar returns appear with our Clear and Max Modes.
INTERNAL GPS
GPS antenna built into the head unit.
UNIMAP CARTOGRAPHY
The Humminbird UniMap is a built-in map covering the contiguous US coastline, inland lakes and rivers at 30 metres per pixel resolution.
AUTOCHART LIVE
Make a map where there is no map. Our patent pending AutoChart Live allows you to create digital, detailed maps live and on the water. You can also use it to enhance your existing charts.
DOWN IMAGING SONAR
Get a fish-eye's view of what's happening below your boat. Incredible images are created with High-frequency sound waves.
DUALBEAM PLUS SONAR
Two beams combine for great detail and a wide coverage area. Use the narrow beam for high-accuracy returns and bottom. Use the wide beam when you want a larger search area.
UPGRADEABLE SOFTWARE
Access software updates to enhance the performance of your Humminbird unit through the My Humminbird section of their website.
SMARTSTRIKE
SmartStrike takes you straight to the action by showing you where the fish are biting at any given moment.
MICRO SD CARD READER
Use for advanced cartography or to save screenshots, sonar recordings and waypoints or to update your units software.
SPECIFICATIONS
Display Size - Diagonal: 5"
Display Pixel Matrix: 800H X 480V
Display Type: Colour TFT
Display Colours Grayscale: 16-bit
Sonar Standard: CHIRP/Down Imaging/DualBeam PLUS
Standard Sonar Coverage: 16°, 28°, 45° & 75° @ -10db
Standard Sonar Frequency: 200/455/800 kHz
Sonar Optional: 50/83 kHz
Target Separation: 2.5"
Power Output RMS: 500 Watts
Power Output Peak to Peak: 4000 Watts
Depth Capability: 600 ft
Temperature: Built-In Transducer
Speed: GPS Speed Included
Backlight: LED
Unit Size - Gimbal Mount: 7.55"W x 4.64"H x 3.3"D
Mount A Type: Gimbal Mount
Unit Size - Indash Mount: 7.55"W x 4.28"D x 1.13"D
Mounting Options: In-Dash Mount
Transducer Standard: XNT 9 DI T
Transducer Mounting: Transom
Optional Sonar: CHIRP
Power Input: 10.8-20 VDC
Power Draw: 600 mA
GPS Receiver: Included
GPS Tracking: Included
GPS Chartplotting: Included
Waypoints, Routes, Tracks/Points: 2,750, 47, 50/20,000
Humminbird Mapping: Optional
Navionics+: Included
Navionics Platinum+: Optional
SwitchFire Sonar: Included
Humminbird PC: Included
Upgradable Internal Software: Included
Split Screen Zoom: Included
Split Screen Bottom Lock: Included
Large Digits View: Included
Wide/Narrow Cone Split Screen: Included
Custom View Selections: Included
Custom Digital Readout: Included
Temperature Alarm: Included
Freeze Frame: Included
Instant Image Update: Included
Selective Fish ID+: Included
Real Time Sonar: Included
Triplog: Optional
X-Press Menu System: Included
MMC Others: Micro SD
Card Reader Available: Yes
# Card Slots: 1
-
